Small size diameter roller conveyor are suitable for moving light and small size goods.
Details
1.roller diameter：Ø19mm
2.frame： 60mm U-steel
3.width: 100mm～500mm
4.Load capacity: max 44kg
| roller width W(mm) |
100 |
200 |
300 |
300 |
400 |
500 |
| conveyor width W＋75(mm) |
175 |
275 |
375 |
375 |
475 |
575 |
| roller load capacity (kg) |
44 |
21 |
14 |
14 |
10 |
8 |
| conveyor weight 3,000L(kg) |
20P |
24.6 |
31.2 |
37.8 |
37.8 |
44.4 |
51 |
| 25P |
22.2 |
27.6 |
32.9 |
32.9 |
38.3 |
43.6 |
| roller weight(shaft) (g) |
80 |
121 |
162 |
162 |
203 |
244 |
|
